Foner Books’ Computer Repair Flowcharts
As far as visual aids in troubleshooting repairs goes, one of the best visual aids is the flowchart, and in the computer repair industry that holds true as well. It’s easier to follow a simple thread from the top down to the bottom than to go from paragraph to paragraph on a wall of text using checklists. On that note, have you ever checked out the Foner Books’ PC Repair Flowchart book?
Here you can view and download some of the charts included in the book, which you can buy here. Eight of the troubleshooting flowcharts are listed on this page, which you can view and use for troubleshooting, such as Power Supply Failure, Video Card and Display, CPU, RAM and Motherboard, Hard Drive Failure, CD and DVD Failure, Modem Failure, and Sound Card Diagnostics. Some are a little old, but most of it still holds true.
Also included is the Boot Failure Troubleshooting Poster, which is a 30″ by 30″ printable PDF file, which you’ll need to zoom into to read it.
While flowcharts are a great way for beginners to get started in diagnostic procedures, these charts aren’t for those new to general computing without any knowledge of basic repairs. There aren’t any descriptions of basic hardware functions, so it’s more for technicians and perhaps beginner Technicians who are looking for a useful way to perform diagnostics and get a routine down. It’s easy for veteran Techs to forget a step or two occasionally, and just missing one step could throw the whole diagnosis off, so it’s a helpful book for experienced Techs as well.
One of the features I appreciated about the book was the approach towards diagnosis procedure that pushes part swapping off as a last resort for those who don’t have a large stock of parts available for that. I don’t usually carry a lot of spare parts around, and even though I do have access to shops that carry spare parts, it’s useful not to have to run and get them if the diagnosis falls short of having to swap them out with another part, especially if I’ll never need to use that part again in its useful lifetime.
You can purchase a paperback version on Amazon or purchase the eBook on their site, and if you’ve already got the book, post a comment below about what you appreciate about it, or what you appreciate about the flowcharts in general.
